Marin Gestalt X10

ADVENTURE ON AND OFF-ROAD RIDING

LONG DISTANCE COMMUTING

GRAVEL RIDING

The Gestalt X is the mountain biker’s dropbar bike with reliable and simple 1x drivetrains, large tire clearance, and dropper post routing for better off road control, and on road descending stability.

Updated for 2023 with an all-new frame, with mountain bike inspired geometry, featuring 10mm longer chainstays and a 67.5° headtube angle for a more stable ride when getting off the beaten path. Tire clearance is increased, and the frame will now accommodate tires up to 700x50mm or 27.5 x 2.1".

SPECIFICATIONS

• FRAME

  Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle

• FORK

  Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets

• RIMS

  Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific

• HUB, REAR

  Forged Aluminum Alloy, Disc, 32H

• HUB, FRONT

  Forged Aluminum Alloy, Disc, 32H

• SPOKE, NIPPLES

  14g Black Stainless Steel

• TIRES

  Vee Tire Co., Rocket Man, 700x44, Tubeless Compatible

• DERAILLEUR, REAR

  MicroSHIFT Advent X 10-Speed Wide-Range

• DERAILLEUR, FRONT

  -

• SHIFT LEVER

  MicroSHIFT Advent X 10-Speed

• CRANKSET

  Forged Alloy 1x10, Hollow CrMo Spindle, Narrow Wide 42T

• BOTTOM BRACKET

  External Sealed Cartridge Bearings

• CHAIN

  KMC X10

• CASSETTE

  SunRace 10-Speed, 11-51T

• BRAKE, FRONT

  Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor

• BRAKE, REAR

  Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor

• BRAKE LEVERS

  MicroSHIFT Advent X

• HANDLEBAR

  Marin Butted Alloy, Compact 16º Flared Drop

• STEM

  Marin 3D Forged Alloy

• GRIPS

  Marin Shock Absorbing Perforated Tape

• HEADSET

  FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”

• SEATPOST

  Marin Alloy, 27.2mm

• SADDLE

  Marin Beyond Road Concept

• PEDALS

  -

• EXTRAS

  Bolt-On Thru-Axles F and R

Specifications, pricing, and availability are subject to change without notice.
